|Type:||Single Flanged Expansion Joint|
|Size:||10″ & 14″ NPS | 13″ & 16-1/2″ OAL|
|Material:||304 Stainless Steel | CS|
|Design||203°F Operating Temperature|
|Testing:||100% Dye Penetrant | Hydro-tested|
U.S. Bellows designed these 10″ and 14″ NPS single expansion joints for a pipeline in Oklahoma. They have an overall length of 13″ and 16-1/2″. The bellows, liners, covers, and flanges are fabricated from 304 stainless steel, and the tie rods are carbon steel. They are designed for an operating temperature of 203°F at 15 psig. The expansion joints were 100% dye-penetrant and hydro-tested prior to shipment.
